Mastering Rack Customization:
30 Years of Mechanical Precision
From Complex AI Geometries to Tier 1 Massive Deployments—We Engineer the Bespoke Physical Infrastructure that Defines the Future of Compute.
Your Design Partner, From Concept to Scale
We offer more than manufacturing; we offer Co-Engineering Expertise.
Tier 1 Proven
Pedigree
Our chassis guarantees business continuity by maintaining zero-deflection structural integrity even under extreme dynamic loads.
Thermal-First
Engineering
We design with fluid dynamics in mind. Our rack solutions are optimized for the transition from air-cooled to high-flow liquid-cooling architectures, ensuring zero-bottleneck heat dissipation.
Certified
Transportability
Engineered for safe global deployment through rigorous ASTM D4169 testing.
Industry-Leading
Seismic Resilience
Engineered to withstand Magnitude 8.3 earthquakes (Zone 4), our Tier 1 chassis ensures zero-deflection structural integrity for high-value AI assets.
MGX 1.1 Rack Series
NVIDIA MGX Modular Architecture for AI / PC
| Series No |
ARK-48MGSM-7612114-B1 ARK-48MGSM-7612114-W1 |
ARK-52MGSM-7612114-B1 ARK-52MGSM-7612114-W1 |
ARK-52MGSM-6012114-B1 |
| Height |
48U(2288mm) |
[Please fill in] | [Please fill in] |
| Dimension (Width) |
762mm (30") |
762mm (30") |
[Please fill in] |
| Dimension (Depth) |
1200mm (48“ ) |
1200mm (48“ ) |
1200mm (48“ ) |
| Weight (kg) |
370kg (816 lb) |
[Please fill in] |
370kg (816 lb) |
| Static Load Capacity |
2500kg (5512 lb) |
2500kg (5512 lb) |
2500kg (5512 lb) |
| IP Grade | IP20 | IP20 | IP20 |
| Power Shelf Locations | Per Suggested NVIDIA Configuration | Per Suggested NVIDIA Configuration | Per Suggested NVIDIA Configuration |
| Busbars |
Included |
Included |
Included |
MGX 1.2 Rack Series
NVIDIA MGX Modular Architecture for AI / PC
| Series No |
ARK-42MGSM-6012050-B1 |
ARK-48MGSM-6012050-B1 |
ARK-52MGSM-6012050-B1 |
| Height |
42U (2021mm) |
48U (2288mm) |
52U (2450mm) |
| Dimension (Width) |
600mm (23.62") |
600mm (23.62") |
600mm (23.62") |
| Dimension (Depth) | 1200mm (48“ ) | 1200mm (48“ ) | 1200mm (48“ ) |
| Weight (kg) |
320kg (705.5 lb) |
350kg (772 lb) |
370kg (816 lb) |
| Static Load Capacity |
2500kg (5512 lb) |
2500kg (5512 lb) | 2500kg (5512 lb) |
| IP Grade | IP20 | IP20 | IP20 |
| Power Shelf Locations | Per Suggested NVIDIA Configuration | Per Suggested NVIDIA Configuration | Per Suggested NVIDIA Configuration |
| Busbars |
Included |
Included |
Included |
| Series No |
ARK-48MGSM-7512050-B1 |
ARK-52MGSM-7512050-B1 |
| Height |
48U (2288mm) |
52U (2450mm) |
| Dimension (Width) |
750mm (29.5") |
750mm (29.5") |
| Dimension (Depth) | 1200mm (48“ ) | 1200mm (48“ ) |
| Weight (kg) |
370kg (816 lb) |
398kg (877 lb) |
| Static Load Capacity | 2500kg (5512 lb) | 2500kg (5512 lb) |
| IP Grade | IP20 | IP20 |
| Power Shelf Locations | Per Suggested NVIDIA Configuration | Per Suggested NVIDIA Configuration |
| Busbars |
Included |
Included |
EIA 19" Rack Series
EIA-310 19" Legacy Enterprise Standard
| Series No |
ARK-42SESM-80140-B1 |
ARK-48SESM-75120-B1 |
ARK-52SESM-75120-B1 |
| Height |
42U (2050mm) |
48U (2317mm) |
52U (2494mm) |
| Dimension (Width) |
800mm (31.5") |
750mm (29.5") |
750mm (29.5") |
| Dimension (Depth) |
1400mm (55.1“ ) |
1200mm (48“ ) | 1200mm (48“ ) |
| Weight (kg) |
300kg (661 lb) |
300kg (661 lb) |
330kg (728 lb) |
| Static Load Capacity |
2268kg (5000 lb) |
2268kg (5000 lb) | 2268kg (5000 lb) |
| IP Grade |
IP20 |
IP20 |
IP20 |
